The Simplex 565-087 is the board-level replacement for the Graphic 24-Point I/O used in Simplex 4100, 4100+ and Universal Transponder equipment. Its lamp driver circuitry lets a graphic annunciator of LEDs and switches be wired point by point to the panel.
- 24 points in any mix of inputs and outputs
- Lamp drivers for On Steady, Slow Pulse and Fast Pulse annunciation
- Inputs can be unsupervised, supervised for opens, supervised for opens and shorts, or Hands Off Auto
- Standby 55 mA at 8 VDC and 50 mA at 24 VDC; alarm 75 mA plus loads
- 150 mA maximum per output
- Operating temperature 32 to 120 °F (0 to 49 °C)
Not the same as the plain 24-point I/O interface boards (562-789 / 562-856). Confirm the part number on the board you are replacing.
| Brand | Simplex |
|---|---|
| Manufacturer part number | 565-087 |
| Product type | Modules |
| Shipping weight | 0.99 lb |
| Condition | Brand new, factory sealed |
| Warranty | 1 year |
| Currency | Canadian dollars (CAD) |
