The Simplex 4100-0620 is the Basic Transponder Interface Card (TIC) for 4100ES and 4100U fire alarm control units. It is the addressable card that lets a remote transponder cabinet answer to the host panel, carrying the Remote Unit Interface (RUI) input, the audio riser interface and the port for the other bay modules.
- 24 VDC rated, 18 to 33 VDC operating range
- Supplies 8 V at 1 A to the bay modules
- 36 mA maximum input current with no 8 V load
- RUI wiring 18 to 12 AWG, supervised and power-limited; Class A or B up to 2,500 ft
- Up to 31 transponders per panel; mounts in Block A of the bay
Card only: the assembled transponder is the 4100-9600. The 4100-0625 is the local mode TIC; riser cards are 4100-0621 (analog) and 4100-0622 (digital).
| Brand | Simplex |
|---|---|
| Manufacturer part number | 4100-0620 |
| Product type | Modules |
| Shipping weight | 0.99 lb |
| Condition | Brand new, factory sealed |
| Warranty | 1 year |
| Currency | Canadian dollars (CAD) |
