The Protectowire PHSC-172-XCR is a fixed-temperature digital linear heat detector cable with a 172°F (78°C) alarm point and an XCR (Extreme Corrosion Resistance) fluoropolymer jacket. Two heat-sensitive insulated steel conductors short together at the first point that reaches the rated temperature, signalling an alarm on the connected initiating circuit.
- Alarm temperature 172°F (78°C)
- Maximum ambient 130°F (54°C); minimum -40°F (-40°C)
- XCR jacket for abrasion and chemical resistance in industrial applications, indoors or outdoors
- Maximum listed spacing: UL/cUL 50 ft (15.2 m), FM 30 ft (9.1 m)
- Maximum voltage rating 30 VAC, 42 VDC; conductor resistance 0.185 ohms/ft
- Nominal 5/32 in. (4 mm) diameter; minimum bend radius 2.5 in.
- Can share an initiating circuit with pull stations, spot heat and smoke detectors
A messenger-wire version is available with the -M suffix.
| Brand | Protectowire |
|---|---|
| Manufacturer part number | PHSC-172-XCR |
| Product type | Heat Detectors |
| Shipping weight | 0.99 lb |
| Condition | Brand new, factory sealed |
| Warranty | 1 year |
| Currency | Canadian dollars (CAD) |
