The Bosch D296 is a 24 V long-range projected beam smoke detector with separate transmitter and receiver, for large open volumes such as atriums, arenas, churches and warehouses. The receiver compares the pulsed infrared beam with a selected threshold and compensates automatically for dust build-up on the covers.
- Range 30 ft (9 m) to 350 ft (107 m); maximum spacing 60 ft (18 m) between systems
- Field-selectable sensitivity: 20, 30, 40, 50, 60 or 70% obscuration
- 18.0 to 32.0 VDC; receiver 45 mA standby, 70 mA alarm; transmitter 20 mA standby
- Conventional four-wire signalling; not for circuits using alarm verification
- Adjustable optics: 90° either side horizontally, 10° vertically
- 7 x 5.5 x 5.5 in.; indoor dry locations
- Includes D344-RL remote indicator plate, D308 field test kit and D1005 test cable
The D297 is the 12 VDC version.
| Brand | Bosch |
|---|---|
| Manufacturer part number | D296 |
| Product type | Beam Detectors |
| Shipping weight | 0.99 lb |
| Condition | Brand new, factory sealed |
| Warranty | 1 year |
| Currency | Canadian dollars (CAD) |
